12V Universal Under Dash Air Conditioning A/C Kit with remote control 12 volt under dash ac Kit 10000btu Electric Air Conditioner for car ac system semi trucks Motorhome SUV Camper Van Auto RV Truck

Upgrade 12 Volt Under dash Electric Drive air conditionerAdvantage:Low Noise8 hour Flame-out using3 in 1 upgrade easy installPackage List1*Condenser*Fan*Dryer Bottle（Dimension：14*18*in with bottle，OR interface）Fan（14*18-12V ，including 2P mother shell + 6.3 inserts) with carton）1*Outlet1*Integrated Electric Compressor1.Wiring Harness1*Fittings KitSCROLLCOMPRESSOR SPECIFICATIONRefrigerating capacity: 1.94kw maxRated Voltage:12 VoltApplication:Automotive air-conditionRefrigerant: R134aCompressor cooling:Inhalation refrigerant coolingDisplacement: 12ml/reRefrigerator oil: EMKARATE RL68H/100mlNote:1.The total leakage of the compressor is not greater than 5g/year.2.The noise is not greater than 74dB in rated speed.3.Insulation resistance must be greater than 20MΩ .4.The tolerance of None remarked dimensionsmay be accordance with GB1804-m.5. The performance of all unmentioned are in accordance withGB/T 22068-2018.

• 【Fast-Cooling】This type AC adopt 20CC Electric Scroll Compressor Stronger cooling capacity, faster cooling speed. This AC is New Upgrade of the Under dash AC kit, the 10000BTU cooling capacity in summer allows you to enjoy a cool atmosphere.
• 【Remote Control】The clear LED display screen is simple and easy to operate, and the accompanying remote control only needs to be equipped with a battery to be used remotely. Sitting in the driver's seat, the temperature of the air conditioning can be directly adjusted.
• 【Upgrade Design】Combine traditional Receiver Dryers and condenser fan and condenser, Easy Install and connecting.The integrated design helps to reduce leakage points, optimize internal flow channels, thereby improving overall heat exchange efficiency and system stability.
• 【New energy Fuel saving】This under dash ac is driven by battery. Eliminating the fuel consumption of traditional air conditioning, directly improving the vehicle's range, and achieving true "energy saving". The system can directly call on the battery power to maintain operation after the vehicle is turned off or the main power is turned off. Powered by electricity, it is expected to save up to $6000 in fuel costs annually.
• 【Fit most vehicles】This type of under dash ac kit is suitable for most cars, whether they are traditional or new energy vehicles, as well as trucks, RVs, campers, buses, boats, etc. Please confirm the product size (internal unit: 15.7 * 12.6 * 5.5 inches) before purchasing
• 【Attention】 This air conditioning system is Water Heating, which warms the water tank by heating the engine coolant. The blower blows the warm air out of the car to achieve heating.If you have any questions about the heating function, please feel free to consult us and we will reply to you within 24 hours.
• 【Shipping Notice】This product is shipped separately in two packages: the internal unit and the external unit, and the packages may be delivered at different times. If you have any questions about the package and products, you can contact our customer service at any time.
